ECRM Mako 4 CTP - Requirements and Safety

AG45134 Rev. 3 1 - 1
1
Requirements
and Safety
Introduction to the System
The Mako 4 CTP images printing plates. Plates are manually
loaded by positioning the plate in the pin registration system and
closing the pinch rollers. Imaging of the plate starts with the push of
a button. When the imaging is complete, the exposed plate
automatically moves onto the media transport, which feeds the
plate into a customer-supplied plate processor.
All operations must be performed in a safe-light environment.
System Requirements
System Power and Heat Dissipation
Power (maximum) 90 - 264 Volts; 3 Amps; 250 Watt
50/60Hz, single phase.
Heat Dissipation 850 BTU/hour
Environmental Requirements
Temperature - 70 - 77 degrees F (21 - 25 degrees C)
Humidity 45 - 65%, non-condensing.
Note: Operating the system outside of the ranges specified
above may affect performance.
