4 - 6 AG45134 Rev. 3
Cleaning the Media Transport Belt
Step 1. Use the User Maintenance Menu to run the transport.
Step 2. Using a lint-free cloth moistened with Fantastik (ECRM HB2456),
remove debris from the belt.
Step 3. Using a second lint-free cloth moistened with alcohol, rub down
the belt.
Clearing Misfeeds
Two methods for clearing a misfeed are presented below.
• Use Method 1 if you are using a notch-registered pin bar.
• Use Method 2 if you are using an edge-registered pin bar.
Method 1
Step 1. Lift the pinch roller bar to open the roller.
Step 2. Carefully pull the jammed media out of the rollers.
Step 3. Press the OK button on the control panel.
Step 4. Resume normal operation.
Method 2
When an edge-registered pin bar is used, a third “internal”
registration pin is activated. The location of this pin (which you can
feel but not see when you load a plate) is shown in Figure 4-4. The
pin moves up into the media path when the pinch roller bar is raised,
and it drops below the media path when the bar is lowered.
