ECTIVE CSI Series User Manual

ECTIVE CSI & SSI Series 11
Frontansicht: SSI 10 bis SSI 30
1. Schalter ECO/OFF/UPS
2. LED „Power“
3. LED „Solar“
4. LED „Fehler“
5. LED „Charge“
6. LED „AC-In“
7. LED „By-Pass“
8. Anschluss
Fernbedienung
9. USB-Buchse
10. Anschluss
Landstrom
11. Schutzerdung
12. MC4 Anschluss-
stecker Solar
13. 230 V Schuko-
Steckdose
9
8
4
1
5
6
7
10
12
3
2
11
+ -
13

ECTIVE CSI Series Specifications

General

Waveform	Pure Sine Wave
Efficiency	>90%
USB Output	5V/2.1A
Input Voltage	12V / 24V
Protection Features	Overload, Short Circuit, Over Temperature
Operating Temperature	-20°C - +50°C
Dimensions	Varies by model
Weight	Varies by model
Cooling	Fan Cooling
