o Check all the system connectors.
o Try restarting ICON™
o Listen for the track motors. If the motors run but the track doesn’t turn there is a problem
with the gearing or shaft pins.
o Try changing tracks. (ICON will require a restart.)
• Track Raise will not move.
o Check the linkage between the top linkage and the encoder feedback
o Check the connector to the camera raise motor.
o Try restarting ICON.
Reel Problems
• Tether distance does not read correctly.
o Check that the pressure wheel is pressing the tether against the payout sheave. If the
tether is being pulled up from the sheave instead of down, it may be disengaged from the
sheave.
o Check that the units are set properly in the graphical overlay.
o Recalibrate distance encoder.
o Ensure that the correct COM port is selected in the control software.
