Eddyfi Technologies INUKTUN VERSATRAX 100 User Manual

Versatrax 100™
Document: UMDT013103.docm
Revision: A13
Created by: KJB
Date: 15 Oct 2019
3070984-A13
Source Location: C:\ePDM\ISLEng\products\dt-versatrax100mkii\manuals\UMDT013103.docm
Page 6 of 47
User Manual
Specifications
Min Vehicle
Dimensions
Parallel
331 x 170 x 150 mm (13 x 7 x 6 in)
Inline
848 x 100 x 100 mm (33 x 4 x in)
Vehicle
Weight
Error!
Bookmark not defined.
Parallel
6.8 kg (15 lb)
Inline
5.0 kg (11 lb)
Depth Rating
60 m (200 ft)
Pipe Size
Range
2
Parallel
Camera Centered
200 – 300 mm (8 – 12 in)
Camera Centered with Extension
300 – 600 mm (12 – 24 in)
Camera not Centered
600 mm (24 in) – Flat
Inline
Camera Centered with Skids
100 – 150 mm (4 – 6 in)
Min Bend
Radius
3
Parallel
2D @ 200 mm (8 in)
Inline
7D @ 100 mm (4 in)
Maximum Tether Length
4
300 m (1,000 ft)
Tracks
2x Microtracs™ 4000
Camera
Front
Standard
Spectrum 45™
Option
Sapphire™
Option (Parallel Only)
Spectrum 90™
Rear
Standard (Inline Only)
Onyx™
Option (Parallel Only)
Sapphire™
Lights
(Parallel Only)
2x 801 Lights
Reel
Optional portable tether reel with payout encoder
Parallel Chassis Optional Components
Magnet Kit
Weight Kit – 3.6 kg (8 lb)
Camera Extension Kit
Power Requirements
100 – 240 VAC 50/60Hz, 5A
Operating Temperature
0 – 50 ºC (32 – 122 ºF)
Storage Temperature
-20° – 60 ºC (-4 – 140 ºF)
1
Weights may vary depending on optional components
2
Specified pipe sizes are internal diameters
3
As pipe size increases Min Bend Radius decreases
4
Actual travel distance may be decreased depending on inspection geometry (traction and number of bends)
