210E / 210ECL / 2010 / 2010ECL / 2018ECL SERIES SIGNAL MONITOR
OPERATIONS MANUAL
Eberle Design Inc. Page 27
5.3 RED INTERFACE CONNECTOR (P1)
This connector provides the required inputs for the Signal Monitor to monitor the Red Field
Signal outputs. It is polarized to insure proper mating with the adapter cable. Ejector
latches are included to facilitate removal and prevents the cable from inadvertently
disconnecting. The Signal Monitor will function as a standard 210 Signal Monitor
when the cable is disconnected.
