Section 8
SPECIFICATIONS
8.1 ELECTRICAL
8.1.1 POWER REQUIREMENTS
Operating Line Voltage .................................................................................. 75 to 135 Vrms
Operating Line Frequency ......................................................................................... 60 _+3Hz
Power Consumption .......................................................................................... 5W (nominal)
8.1.2 AC VOLTAGE MONITORS
Green Signal Inputs (no detect) ................................. less than 15 Vrms
(detect) ................................. greater than 25 Vrms
Yellow signal Inputs (no detect) ................................. less than 15 Vrms
(detect) ................................. greater than 25 Vrms
Red Signal Inputs (no detect) ................................. less than 50 Vrms
(detect) ................................. greater than 70 Vrms
Red Enable Input (no detect) .................................. less than 50 Vrms
(detect) ................................. greater than 70 Vrms
Special Function Inputs (no detect) .................................. less than 50 Vrms
(detect) ................................. greater than 70 Vrms
Watchdog Enable (AC level) (enable) ......................... greater than 103 _+2 Vrms
(disable) ................................ less than 98 _+2 Vrms
LEDguard
®
Low Threshold Signal Inputs
No Detect ................................... less than 15 Vrms
Detect .................................... greater than 25 Vrms
LEDguard
®
High Threshold Signal Inputs
No Detect ................................... less than 50 Vrms
Detect .................................... greater than 70 Vrms
AC Line 2010 Brown-out (SEL5) (drop-out) ............................................. 98 _+2 Vrms
(restore) ............................................. 103 _+2 Vrms
AC Line 210E Brown-out (drop-out) ............................................. 92 _+2 Vrms
(restore) ............................................... 98 _+2 Vrms
8.1.3 DC VOLTAGE MONITORS
+24VDC Input (fault) ......................................... less than +18 Vdc
(no fault) ............................... greater than +22 Vdc
External Reset Input (true) ........................................... less than 3.5 Vdc
(False) ................................... greater than 8.5 Vdc
Watchdog Input (true) ........................................... less than 3.5 Vdc
(false) .................................... greater than 8.5 Vdc
8.1.4 OUTPUTS
Relay Output
AC Contact Rating ................................................................................... 3A @ 120 Vac
DC Contact Rating ..................................................................................... 3A @ 30 Vdc
Stop Time Output ........................................................................................ 50 mA @ 30 Vdc
