EDI 210E - 9.1 Monitor Unit Connector (P6)

210E / 210ECL / 2010 / 2010ECL / 2018ECL SERIES SIGNAL MONITOR
OPERATIONS MANUAL
Eberle Design Inc. Page 34
Section 9
WIRING ASSIGNMENTS
9.1 MONITOR UNIT CONNECTOR (P6)
9.1.1 SIXTEEN CHANNEL
Pin #
Function
Pin #
Function
1
CHANNEL 2 GREEN
A
CHANNEL 2 YELLOW
2
CHANNEL 13 GREEN
B
CHANNEL 6 GREEN
3
CHANNEL 6 YELLOW
C
CHANNEL 15 GREEN
4
CHANNEL 4 GREEN
D
CHANNEL 4 YELLOW
5
CHANNEL 14 GREEN
E
CHANNEL 8 GREEN
6
CHANNEL 8 YELLOW
F
CHANNEL 16 GREEN
7
CHANNEL 5 GREEN
H
CHANNEL 5 YELLOW
8
CHANNEL 13 YELLOW
J
CHANNEL 1 GREEN
9
CHANNEL 1 YELLOW
K
CHANNEL 15 YELLOW
10
CHANNEL 7 GREEN
L
CHANNEL 7 YELLOW
11
CHANNEL 14 YELLOW
M
CHANNEL 3 GREEN
12
CHANNEL 3 YELLOW
N
CHANNEL 16 YELLOW
13
CHANNEL 9 GREEN
P
UNASSIGNED
14
UNASSIGNED
R
CHANNEL 10 GREEN
15
CHANNEL 11 YELLOW
S
CHANNEL 11 GREEN
16
CHANNEL 9 YELLOW
T
UNASSIGNED
17
UNASSIGNED
U
CHANNEL 10 YELLOW
18
CHANNEL 12 YELLOW
V
CHANNEL 12 GREEN
19
UNASSIGNED
W
UNASSIGNED
20
CHASSIS GROUND
X
UNASSIGNED
21
AC-
Y
DC GROUND
22
WATCHDOG TIMER
Z
EXTERNAL RESET
23
+24VDC
AA
+24VDC
24
[PINS 24 & 25
ARE TIED TOGETHER]
BB
STOP TIME
25
CC
UNASSIGNED
26
UNASSIGNED
DD
UNASSIGNED
27
OUTPUT SW, SIDE #3
EE
OUTPUT SW, SIDE #2 (MC Coil)
28
OUTPUT SW, SIDE #1
FF
AC+ LINE
NOTE: Pins 23 and AA are shorted together. Maximum current rating is 500 milliamps.
Pins 24 and 25 are shorted together. The Monitor circuit and the Program
Card mate with a 28/56 pin double sided edge-card connector having
0.156" centers.
- WARNING -
PIN 27 OF THE MAIN CONNECTOR (P6) PROVIDES THE CLOSED CONTACT OF
THE OUTPUT RELAY WHEN THE MONITOR IS IN THE NO-FAULT STATE. WHEN
THE MONITOR IS IN THE NO-FAULT STATE AND THE AUTO/FLASH SWITCH IS
IN THE FLASH POSITION, AC LINE VOLTAGE MAY BE PRESENT ON PIN 27.
THIS PIN WAS PREVIOUSLY DEFINED AS A “NO-CONNECT” PIN IN LEGACY
EQUIPMENT. TO PREVENT POTENTIAL EXPOSURE TO ELECTRICAL SHOCK,
BEFORE INSTALLING THIS MONITOR THE USER IS CAUTIONED TO CHECK
THAT THE CABINET WIRING IS COMPATIBLE WITH THE USE OF THIS PIN AS A
SOURCE OF AC LINE VOLTAGE.
