210E / 210ECL / 2010 / 2010ECL / 2018ECL SERIES SIGNAL MONITOR
OPERATIONS MANUAL
Eberle Design Inc. Page 23
4.4.3 WDT TIMING SWITCH
Switch #3 of SW3 is labeled "WD 1.0 SEC". When this switch is in the ON position, the
Watchdog fault time is set to 1.0 _+0.1 seconds. When this switch is in the OFF position, the
Watchdog fault time is set to 1.5 _+0.1 seconds. See Section 1.2.3.
4.4.4 GY ENABLE SWITCH
Switch #4 of SW3 is labeled "GY ENABLE". When this switch is in the ON position, all
channels will be monitored for a simultaneous active Green and Yellow input regardless of
the Red Enable input. See Section 2.3.1.
4.4.5 POLARITY SWITCH
Switch #5 of SW3 is labeled "POLARITY". When this switch is in the OFF position, the
active state of the two Special Function inputs is when AC+ present. When this switch is in
the ON position, the active state of the Special Function input #1 is when AC+ present is
not present. The switch does not affect the polarity of Special Function #2. See 4.1.2.
4.4.6 LEDGUARD SWITCH
Switch #6 of SW3 is labeled "LEDguard". When this switch is in the ON position, the
LEDguard
®
threshold mode is enabled. See Section 2.6.
4.4.7 RF SSM SWITCH
Switch #7 of SW3 is labeled "RF SSM". When this switch is in the ON position, then each
channel will be monitored for a Red Fail condition if the corresponding SSM switch is in the
On position. See Section 2.2.1.
4.4.8 FYA MODE SWITCH
Switch #8 of SW3 is labeled "FYA compact". When this switch is in the ON position, then
the Flashing Yellow Arrow monitoring mode is selected as FYAc Mode as described in
Section 2.20.2. When this switch is in the OFF position, then the Flashing Yellow Arrow
monitoring mode is selected as FYA Mode as described in Section 2.20.1.
The FYA or FYAc monitoring mode is only active if one or more FYA channel pairs are
enabled with Option switches #8, 9, 10, or 11 described in Section 4.4.8.1.
4.4.8.1 FYA CHANNEL PAIR ENABLE SWITCHES
To enable a channel pair for FYA operation, place the Option DIP Switch labeled “FYA x-y”
(where “x-y” is 1-9, 3-10, 5-11, or 7-12) in the On position. See Sections 2.20.1.2 and
2.20.2.2.
4.5 SELECT JUMPER PROGRAMMING
The Signal Monitor also provides jumper options to modify the monitor operation. The
Select jumpers are labeled SEL1 through SEL16. SEL6 through SEL16 are reserved for
EDI configuration programming and should not be modified except by the factory.
4.5.1 WATCHDOG LATCH SELECT (SEL1)
The WDT Latch select determines whether the WDT Error fault mode is latched through an
AC Line brownout or not. If the WDT Latch select is not jumpered, an AC Line brownout
condition will reset the WDT ERROR fault mode when the AC Line is restored. The WDT
Error indicator will remain illuminated until a Reset command is issued via the front panel
RESET button or External Reset input. See Section 1.2.3.
If the WDT LATCH select is jumpered, the WDT Error fault mode is maintained until a
Reset command is applied.
