EDI 210E - Eighteen Channel

210E / 210ECL / 2010 / 2010ECL / 2018ECL SERIES SIGNAL MONITOR
OPERATIONS MANUAL
Eberle Design Inc. Page 36
Pin #
Function
Pin #
Function
8
CHANNEL 9 GREEN
J
CHANNEL 8 GREEN
9
CHANNEL 10 GREEN
K
CHANNEL 9 GREEN
10
CHANNEL 11 GREEN
L
CHANNEL 10 GREEN
11
CHANNEL 12 GREEN
M
CHANNEL 11 GREEN
12
CHANNEL 13 GREEN
N
CHANNEL 12 GREEN
13
CHANNEL 14 GREEN
P
CHANNEL 13 GREEN
14
CHANNEL 15 GREEN
R
CHANNEL 14 GREEN
15
CHANNEL 16 GREEN
S
CHANNEL 15 GREEN
16
PROGRAM CARD
T
DC GROUND
17
CHANNEL 1 YELLOW
U
CHANNEL 9 YELLOW
18
CHANNEL 2 YELLOW
V
CHANNEL 10 YELLOW
19
CHANNEL 3 YELLOW
W
CHANNEL 11 YELLOW
20
CHANNEL 4 YELLOW
X
CHANNEL 12 YELLOW
21
CHANNEL 5 YELLOW
Y
CHANNEL 13 YELLOW
22
CHANNEL 6 YELLOW
Z
CHANNEL 14 YELLOW
23
CHANNEL 7 YELLOW
AA
CHANNEL 15 YELLOW
24
CHANNEL 8 YELLOW
BB
CHANNEL 16 YELLOW
25
NO CONNECT
CC
NO CONNECT
26
NO CONNECT
DD
NO CONNECT
27
NO CONNECT
EE
RESERVED
28
YELLOW INHIBIT COMMON
FF
NO CONNECT
=== Mating connector shall be keyed between pins 24 and 25 and also BB and
CC. The Monitor circuit and the Program Card mate with a 28/56 pin
double sided edge-card connector having 0.156" centers.
9.2.2 EIGHTEEN CHANNEL
Pin #
Function
Pin #
Function
1
CHANNEL 2 GREEN
A
CHANNEL 1 GREEN
2
CHANNEL 3 GREEN
B
CHANNEL 2 GREEN
3
CHANNEL 4 GREEN
C
CHANNEL 3 GREEN
4
CHANNEL 5 GREEN
D
CHANNEL 4 GREEN
5
CHANNEL 6 GREEN
E
CHANNEL 5 GREEN
6
CHANNEL 7 GREEN
F
CHANNEL 6 GREEN
7
CHANNEL 8 GREEN
H
CHANNEL 7 GREEN
8
CHANNEL 9 GREEN
J
CHANNEL 8 GREEN
9
CHANNEL 10 GREEN
K
CHANNEL 9 GREEN
10
CHANNEL 11 GREEN
L
CHANNEL 10 GREEN
11
CHANNEL 12 GREEN
M
CHANNEL 11 GREEN
12
CHANNEL 13 GREEN
N
CHANNEL 12 GREEN
13
CHANNEL 14 GREEN
P
CHANNEL 13 GREEN
14
CHANNEL 15 GREEN
R
CHANNEL 14 GREEN
15
CHANNEL 16 GREEN
S
CHANNEL 15 GREEN
16
RESERVED
T
DC GROUND
17
CHANNEL 1 YELLOW
U
CHANNEL 9 YELLOW
18
CHANNEL 2 YELLOW
V
CHANNEL 10 YELLOW
19
CHANNEL 3 YELLOW
W
CHANNEL 11 YELLOW
20
CHANNEL 4 YELLOW
X
CHANNEL 12 YELLOW
21
CHANNEL 5 YELLOW
Y
CHANNEL 13 YELLOW
22
CHANNEL 6 YELLOW
Z
CHANNEL 14 YELLOW
23
CHANNEL 7 YELLOW
AA
CHANNEL 15 YELLOW
24
CHANNEL 8 YELLOW
BB
CHANNEL 16 YELLOW
25
CHANNEL 17 GREEN
CC
CHANNEL 17 YELLOW
