EDI 210E - 8.2 Timing Functions

210E / 210ECL / 2010 / 2010ECL / 2018ECL SERIES SIGNAL MONITOR
OPERATIONS MANUAL
Eberle Design Inc. Page 33
8.2 TIMING FUNCTIONS
Conflict (no fault) ....................................... less than 200 milliseconds
(fault) ....................................... greater than 500 milliseconds
(typical) ....................................................... 350 milliseconds
VDC Failed (no fault) ....................................... less than 200 milliseconds
(fault) ....................................... greater than 500 milliseconds
(typical) ....................................................... 400 milliseconds
Watchdog 1.0 second (no fault) ....................................... less than 900 milliseconds
(fault) ..................................... greater than 1100 milliseconds
(typical) ...................................................... 1000 milliseconds
Watchdog 1.5 second (no fault) ..................................... less than 1400 milliseconds
(fault) ..................................... greater than 1600 milliseconds
(typical) ...................................................... 1500 milliseconds
Red Fail (no fault) ....................................... less than 700 milliseconds
(fault) ..................................... greater than 1000 milliseconds
(typical) ........................................................ 850 milliseconds
Red Fail (2010) (no fault) ..................................... less than 1200 milliseconds
(fault) ..................................... greater than 1500 milliseconds
(typical) ...................................................... 1350 milliseconds
Dual Indication (no fault) ....................................... less than 200 milliseconds
(fault) ....................................... greater than 500 milliseconds
(typical) ....................................................... 400 milliseconds
Dual Indication Long (no fault) ....................................... less than 700 milliseconds
(fault) ..................................... greater than 1000 milliseconds
(typical) ....................................................... 850 milliseconds
Clearance (no fault) ......................................... greater than 2.8 seconds
(fault) .................................................... less than 2.6 seconds
AC Line 2010 Brown-out (drop-out) ............................................. 400 _+50 milliseconds
(restore) ................................................ 400 _+50 milliseconds
AC Line 210E Brown-out (drop-out) ........................................................ 80 _+17 milliseconds
(restore) .................................................. 80 _+17 milliseconds
Minimum flash after restore ........................................................................ 6.0
+_0.5 seconds
Maximum flash after restore ...................................................................... 10.0 +_0.5 seconds
Watchdog (2010) (disable) ................................................ 400 _+50 milliseconds
(enable) ................................................. 400 _+50 milliseconds
Watchdog (210E) (disable) ................................................. 80 _+17 milliseconds
(enable) .................................................. 80 _+17 milliseconds
FYA Flash Rate no fault .................................................... less than 1400 msec
fault .................................................... greater than 1600 msec
8.3 MECHANICAL
Height .................................................................................................................... 9.3 inches
Width ................................................................................................................... 1.38 inches
Depth ................................................................................................................. 10.17 inches
8.4 ENVIRONMENTAL
Storage Temperature Range ........................................................................... -55 to +90
o
C
Operating Temperature Range ........................................................................ -37 to +74
o
C
Humidity Range ......................................................................................... 0 to 95% Relative
