OUTPUT SW, SIDE #1 closes in the fault mode. OUTPUT SW, SIDE #3 opens in the fault
mode.
9.1.2 EIGHTEEN CHANNEL
Pin #
Function
Pin #
Function
1
CHANNEL 2 GREEN
A
CHANNEL 2 YELLOW
2
CHANNEL 13 GREEN
B
CHANNEL 6 GREEN
3
CHANNEL 6 YELLOW
C
CHANNEL 15 GREEN
4
CHANNEL 4 GREEN
D
CHANNEL 4 YELLOW
5
CHANNEL 14 GREEN
E
CHANNEL 8 GREEN
6
CHANNEL 8 YELLOW
F
CHANNEL 16 GREEN
7
CHANNEL 5 GREEN
H
CHANNEL 5 YELLOW
8
CHANNEL 13 YELLOW
J
CHANNEL 1 GREEN
9
CHANNEL 1 YELLOW
K
CHANNEL 15 YELLOW
10
CHANNEL 7 GREEN
L
CHANNEL 7 YELLOW
11
CHANNEL 14 YELLOW
M
CHANNEL 3 GREEN
12
CHANNEL 3 YELLOW
N
CHANNEL 16 YELLOW
13
CHANNEL 9 GREEN
P
CHANNEL 17 YELLOW
14
CHANNEL 17 GREEN
R
CHANNEL 10 GREEN
15
CHANNEL 11 YELLOW
S
CHANNEL 11 GREEN
16
CHANNEL 9 YELLOW
T
CHANNEL 18 YELLOW
17
CHANNEL 18 GREEN
U
CHANNEL 10 YELLOW
18
CHANNEL 12 YELLOW
V
CHANNEL 12 GREEN
19
CHANNEL 17 RED
W
CHANNEL 18 RED
20
CHASSIS GROUND
X
UNASSIGNED
21
AC-
Y
DC GROUND
22
WATCHDOG TIMER
Z
EXTERNAL RESET
23
+24VDC
AA
+24VDC
24
[PINS 24 & 25
ARE TIED TOGETHER]
BB
STOP TIME
25
CC
UNASSIGNED
26
UNASSIGNED
DD
UNASSIGNED
27
OUTPUT SW, SIDE #3
EE
OUTPUT SW, SIDE #2 (MC Coil)
28
OUTPUT SW, SIDE #1
FF
AC+ LINE
NOTE: Pins 23 and AA are shorted together. Maximum current rating is 500 milliamps.
Pins 24 and 25 are shorted together. The Monitor circuit and the Program
Card mate with a 28/56 pin double sided edge-card connector having .156
" centers.
OUTPUT SW, SIDE #1 closes in the fault mode. OUTPUT SW, SIDE #3 opens in the fault
mode.
9.2 PROGRAM CARD CONNECTOR
9.2.1 SIXTEEN CHANNEL
Pin #
Function
Pin #
Function
1
CHANNEL 2 GREEN
A
CHANNEL 1 GREEN
2
CHANNEL 3 GREEN
B
CHANNEL 2 GREEN
3
CHANNEL 4 GREEN
C
CHANNEL 3 GREEN
4
CHANNEL 5 GREEN
D
CHANNEL 4 GREEN
5
CHANNEL 6 GREEN
E
CHANNEL 5 GREEN
6
CHANNEL 7 GREEN
F
CHANNEL 6 GREEN
7
CHANNEL 8 GREEN
H
CHANNEL 7 GREEN
