Edimax EW-7416APn v2 User Manual

23
mode, and link the wired network which these
wireless range extender/access points connected
to together. Up to 4 range extender/access points
can be connected in this mode.
AP Bridge-WDS This mode is similar to ‘AP Bridge to
Multi-Point’, but range extender/access point is
not work in bridge-dedicated mode, and will be
able to accept wireless clients while the range
extender/access point is working as a wireless
bridge.
Universal Repeater This product can act as a wireless range extender
that will help you to extend the networking
wirelessly. The range extender/access point can
act as Station and AP at the same time. It can use
Station function to connect to a Root AP and use
AP function to service all wireless clients within
its coverage.
Please select one wireless operating mode, for detailed descriptions of
every operating mode; please refer to Section 2-4-1 to 2-4-6 listed below.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
