Edimax EW-7416APn v2 User Manual

53
2-7-3 WPA Pre-shared Key
WPA Pre-shared key is the safest encryption method currently, and it’s
recommended to use this encryption method to ensure the safety of your
data.
When you select ‘WPA pre-shared key’ as encryption type, the following
messages will be displayed:
Here are descriptions of every setup item:
WPA Unicast
Cipher Suite
Available options are: WPA (TKIP) and WPA2
(AES). You can select one of them, but you have to
make sure your wireless client support the cipher
you selected.
Pre-shared Key
Format
Please select the format of pre-shared key here,
available options are ‘Passphrase’ (8 to 63
alphanumerical characters) and ‘Hex (64
hexadecimal characters – 0 to 9 and a to f).
Pre-shared Key Please input pre-shared key according to the key
format you selected here. For security reason,
don’t use simple words).
After you finish with setting, please click ‘Apply’, and the following
message will be displayed:

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
