Edimax EW-7416APn v2 User Manual

26
2-4-1-1 Multiple ESSID
This range extender/access point supports four SSIDs. Except the main
SSID (It can be configure in Basic Setting page), you can configure
another three of SSIDs here. With different SSIDs, you can separate the
wireless networks with different SSID name, wireless security, WMM,
and VLAN settings.
Here are descriptions of every setup item:
No. Except Main SSID, you can configure additional
three ESSID here.
Enable Select the box to enable the different additional
ESSID.
SSID Please input the SSID name (the name used to
identify this wireless range extender/access point)
here. You can input up to 32 alphanumerical
characters. PLEASE NOTE THAT ESSID IS
CASE SENSITIVE.
Broadcast SSID Decide if the wireless range extender/access point
NOTE: If you want to configure the wireless security for different
SSID, please go to ‘2-7 Wireless Security’ for more information.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
