Edimax EW-7416APn v2 User Manual

69
3-2 Firmware Upgrade
If there are new firmware of this wireless range extender/access point
available, you can upload the firmware to the range extender/access point
to change the firmware with new one, to get extra functions or problem
fix.
To perform firmware upgrade, please click ‘Upgrade’ on the left of web
management interface, and the following message will be displayed:
Click ‘Browse’ button first, you’ll be prompted to provide the filename of
firmware upgrade file. Please download the latest firmware file from our
website, and use it to upgrade your range extender/access point.
After a firmware upgrade file is selected, click ‘Apply’ button, and the
range extender/access point will start firmware upgrade procedure
automatically. The procedure may take several minutes, please be patient.
NOTE: Never interrupt the upgrade procedure by closing the web
browser or physically disconnect your computer from range
extender/access point. If the firmware you uploaded is corrupt, the
firmware upgrade will fail, and you may have to return this range
extender/access point to the dealer of purchase to ask for help.
(Warranty voids if you interrupted the upgrade procedure).

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
