Edimax EW-7416APn v2 User Manual

45
2-6 Advanced Wireless Settings
This wireless range extender/access point has many advanced wireless
features. Please note that all settings listed here are for experienced users
only, if you’re not sure about the meaning and function of these settings,
please don’t modify them, or the wireless performance will be reduced.
You can click ‘Advanced Setting’ on the left to enter advanced settings
menu, and the following message will be displayed:
Here are descriptions of every setup item:
Fragment
Threshold
Set the Fragment threshold of wireless radio. Do
not modify default value if you don’t know what it
is, default value is 2346
RTS Threshold
Set the RTS threshold of wireless radio. Do not
modify default value if you don’t know what it is,
default value is 2347
Beacon Interval
Set the beacon interval of wireless radio. Do not
modify default value if you don’t know what it is,

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
