Edimax EW-7416APn v2 User Manual

55
2-7-4 WPA RADIUS
WPA Radius is the combination of WPA encryption method and RADIUS
user authentication. If you have a RADIUS authentication server, you can
check the identify of every wireless client by user database.
When you select ‘WPA RADIUS’ as encryption type, the following
messages will be displayed:
Here are descriptions of every setup item:
WPA Unicast
Cipher Suite
You can select WPA encryption type here. AES is
safer than TKIP, but not every wireless client
supports it. Please refer to the specification of your
wireless client to decide which encryption type you
should use.
Use internal MD5
RADIUS Server
Uses built-in RADIUS Server (refer to Section 2-8)
instead of external RADIUS server. If you check
this box, the value in following three fields will be
ignored.
RADIUS Server IP
address
Please input the IP address of RADIUS
authentication server here.
RADIUS Server
Port
Please input the port number of RADIUS
authentication server here. Default value is 1812.
RADIUS Server
Password
Please input the password of RADIUS
authentication server here.
After you finish with setting, please click ‘Apply’, and the following
message will be displayed:

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
