2-5 WPS Setting
Wi-Fi Protected Setup (WPS) is the simplest way to build connection
between wireless network clients and this range extender/access point.
You don’t have to select encryption mode and input a long encryption
passphrase every time when you need to setup a wireless client, you only
have to press a button on wireless client and this range extender/access
point, and the WPS will do the setup for you.
This range extender/access point supports two types of WPS:
Push-Button Configuration (PBC), and PIN code. If you want to use PBC,
you have to switch this range extender/access point to WPS mode and
push a specific button on the wireless client to start WPS mode. You can
push Reset/WPS button of this range extender/access point, or click ‘Start
PBC’ button in the web configuration interface to do this; if you want to
use PIN code, you have to provide the PIN code of the wireless client you
wish to connect to this range extender/access point and then switch the
wireless client to WPS mode. The detailed instructions are listed follow:
To use WPS function to set encrypted connection between this range
extender/access point and WPS-enabled wireless client by WPS, click
‘WPS Setting’ on the left of web management menu, and the following
information will be displayed:
Note: WPS function of this range extender/access point will not
work for those wireless clients do not support WPS.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
