Edimax EW-7416APn v2 User Manual

31
Encryption Display the encryption setting of the range
extender/access points. If you have selected the
range extender/access point with security setting,
you have to go to ‘2-7 Wireless Security’ to set the
same security with the range extender/access point
you want to associate.
Authentication Display the authentication type of the range
extender/access point.
Signal The signal strength of each range extender/access
point will be displayed here. The signal strength is
stronger, the connection quality is better.
Mode Display the wireless modes include 11b, 11b/g or
11b/g/n or 11n only of the range extender/access
points.
Refresh Click this button to refresh the table.
Connection Select an range extender/access point and click
this button to choose the network. The SSID name
of the range extender/access point you have
selected will be displayed in the Main SSID in the
Basic Setting page.
2-4-3 AP Bridge-Point to Point Mode
In this mode, this wireless range extender/access point will connect to
another wireless range extender/access point which uses the same mode,
and all wired Ethernet clients of both wireless range extender/access
points will be connected together. You can use this mode to connect a
network to another network which is physically isolated.
Please note that when you set your range extender/access point to this
mode, it will not accept regular wireless clients anymore.
When you select ‘AP Bridge-Point to Point’, the following options will
be displayed:

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
