Edimax EW-7416APn v2 User Manual

25
PLEASE NOTE THAT ESSID IS CASE
SENSITIVE.
Multiple ESSID The range extender/access point supports multiple
SSID function; up to four SSIDs can be set. If you
want to configure additional SSIDs, please click
this button. For detailed descriptions of the
function, please refer to Section 2-4-1-1.
Channel Number Please select a channel number you wish to use. If
you know a certain channel number is being used
by other wireless range extender/access points
nearby, please refrain from using the same channel
number
Associated Clients Click ‘Show Active Clients’ button and a new
popup window will appear which contains the
information about all wireless clients connected to
this range extender/access point. You can click
‘Refresh’ button in popup window to keep
information up-to-date.
After you finish with setting, please click ‘Apply’, and the following
message will be displayed:
When you see this message, the settings you made is successfully save.
You can click ‘Continue’ button to back to previous page and continue on
other setting items, or click ‘Apply’ button to restart the wireless range
extender/access point and the changes will take effect after about 30
seconds.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
