Edimax EW-7416APn v2 User Manual

52
Default Tx Key You can set up to four sets of WEP key, and you
can decide which key is being used by default here.
If you don’t know which one you should use,
select ‘Key 1’.
Encryption Key 1
to 4
Input WEP key characters here, the number of
characters must be the same as the number
displayed at ‘Key Format’ field. You can use any
alphanumerical characters (0-9, a-z, and A-Z) if
you select ‘ASCII’ key format, and if you select
‘Hex’ as key format, you can use characters 0-9,
a-f, and A-F. You must enter at least one encryption
key here, and if you entered multiple WEP keys,
they should not be same with each other.
Enable 802.1x
Authentication
Check this box to enable 802.1x user
authentication. Please refer to Section 2-7-5 for
detailed instructions.
After you finish with setting, please click ‘Apply’, and the following
message will be displayed:
When you see this message, the settings you made is successfully save.
You can click ‘Continue’ button to back to previous page and continue on
other setting items, or click ‘Apply’ button to restart the wireless range
extender/access point and the changes will take effect after about 30
seconds.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
