Edimax EW-7416APn v2 User Manual

28
Here are descriptions of every setup item:
Band Please select the wireless band you wish to use. By
selecting different band setting, you’ll be able to
allow or deny the wireless client of a certain band.
If you select 2.4GHz (B), 2.4GHz (N), or 2.4GHz
(G), only wireless clients using the wireless band
you select (802.11b, 802.11 Draft-N, or 802.11g)
will be able to connect to this range
extender/access point.
If you select 2.4GHz (B+G), then only wireless
clients using 802.11b and 802.11g band will be
able to connect to this range extender/access point.
If you want to allow 802.11b, 802.11g, and 802.11
Draft-N clients to connect to this range
extender/access point, select 2.4GHz (B+G+N).
Main ESSID Please input the ESSID (the name used to identify
this wireless range extender/access point) here.
You can input up to 32 alphanumerical characters.
PLEASE NOTE THAT ESSID IS CASE
SENSITIVE.
Site Survey When you use this range extender/access point as
a wireless station for Ethernet network device to
have wireless capability, you have to associate it
with a working range extender/access point. Click
‘Select Site Survey’ button, then a “Wireless Site
Survey Table” will pop up. It will list all available
range extender/access points near by. You can
select one range extender/access point in the table
and it will join wireless LAN through this range
extender/access point. Please go to Section 2-4-2-1
for more information about the ‘Wireless Site
Survey Table’.
WLAN MAC For some applications, you may need to designate
a specific MAC address for the range

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
