Edimax EW-7416APn v2 User Manual

43
authentication mode of this range extender/access
point will be displayed here. If you don’t enable
security function of the range extender/access
point before WPS is activated, the range
extender/access point will auto set the security to
WPA (AES) and generate a set of passphrase key
for WPS connection.
Passphrase Key: Displays the WPA passphrase
here, all characters will be replaced by asterisk for
security reason. If encryption is not set on this
range extender/access point, nothing will be
displayed here.
Config Mode There are ‘Registrar’ and ‘Enrollee’ modes for the
WPS connection. When ‘Registrar’ is enabled, the
wireless clients will follow the range
extender/access point’s wireless settings for WPS
connection. When ‘Enrolle’ mode is enabled, the
range extender/access point will follow the
wireless settings of wireless client for WPS
connection.
Start PBC Click ‘Start PBC’ to start Push-Button style WPS
setup procedure. This range extender/access point
will wait for WPS requests from wireless clients for
2 minutes. The ‘WLAN’ LED on the range
extender/access point will be steady on for 2
minutes when this range extender/access point is
waiting for incoming WPS request.
Start PIN Please input the PIN code of the wireless client
you via client wish to connect, and click ‘Start PIN’
button. The ‘WLAN’ LED on the range
extender/access point will be steady on when this
range extender/access point is waiting for
incoming WPS request.
NOTE: When you’re using PBC type WPS setup, you must press
‘PBC’ button (hardware or software) of wireless client within 120
seconds; if you didn’t press PBC button of wireless client within
this time period, please press ‘PBC’ button (hardware or software)
of this range extender/access point again.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
