Edimax EW-7416APn v2 User Manual

58
input username, password, re-type password in
corresponding field, and click ‘Add’ button to add
the user to radius server database. You can click
‘Reset’ to clear the text you typed in above three
fields.
All current radius users will be listed here. If you
want to delete one or more users, check ‘Select’
box of that user, and click ‘Delete Selected’ button;
you can click ‘Delete All’ button to delete all users
in radius server database. You can also click
‘Reset’ button to uncheck all ‘Select’ boxes.
Authentication
Client
You can add allowed radius client IP address here.
Please input client IP, secret key, re-type secret key
in corresponding field, and click ‘Add’ button to
add the IP address to radius server database. You
can click ‘Reset’ to clear the text you typed in
above three fields.
All current IP addresses will be listed here. If you
want to delete one or more addresses, check
‘Select’ box of that address, and click ‘Delete
Selected’ button; you can click ‘Delete All’ button
to delete all addresses in radius server database.
You can also click ‘Reset’ button to uncheck all
‘Select’ boxes.
After you finish with setting, please click ‘Apply’, and the following
message will be displayed:
When you see this message, the settings you made is successfully save.
You can click ‘Continue’ button to back to previous page and continue on

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
