Press the OK button to start the check. The screen displays the following until the checks are
complete:
When the checks are complete, the meter processes any pending commands and the screen
displays:
This message will time out after 10 seconds and the screen will revert to the parent menu. These
checks result in User Interface Command Code 0x000B being added to the Event Log.
When in this menu, the UI buttons perform the following actions:
Left / Right
No effect.
OK
Initiates the check for any pending commands on the HAN
Return
Back to parent menu.
11.5.8 DIAL
The DIAL menu is used for in-service testing, allowing engineers to witness the accumulation of
energy on a smaller scale that is provided on the main screen.
For example:
When in this menu the UI buttons perform the following actions:
Left / Right
No effect.
OK
No effect.
Return
Return to parent menu.
P
r
e
s
s
O
K
t
o
s
t
a
r
t
C
H
E
C
K
I
N
G
C
O
M
P
L
E
T
E
9
9
9
.
9
9
9
(
9
9
)
M
3
