Press the OK button to reset the remaining battery capacity.
If the reset is successful, the screen displays:
If the reset is unsuccessful, the screen displays:
The message will time out after 10 seconds or if dismissed by pressing the OK button and the
screen reverts to Engineering Menu.
The Reset Remaining Battery Capacity operation will result in an Event Log entry with User
Interface Command Code 0x0019.
When in this menu, the UI buttons perform the following functions:
Left / Right
No effect.
OK
Initiates the reset.
Return
Back to parent menu.
11.8 Leave HAN
To initiate the ZigBee network leave process. The meter shall only send a NWK leave message
(announcement) if it has the active network key. If the meter does not have the active network key
then it shall silently leave the network without sending a NWK leave announcement. The backlight
shall remain on for the duration of the procedure.
Left / Right
No effect.
OK
Initiates the HAN leave process
Return
Back to parent menu.
