Introduction
1.4 EST3 System Operation Manual
Feature and function domains
The domain of a feature or function is the group of cabinets on
the network that are affected when the feature or function is
activated. Three domains are available:
• Local: The feature/function affects only the cabinet on
which the 3-LCD Display module is installed
• Group: The feature/function affects a pre-defined group of
cabinets on the network
• Global: The feature/function affects all the cabinets on the
network
A network cabinet may be a part of one or more groups.
Multiple control locations are permitted for any group.
1 6
[3GROUP.CDR]
5234
Group #1 Group #2
Group #3
The configuration of features and functions varies with each
installation. Please consult your site-specific documentation to
determine if any custom features or functions have been
designed into your system.
