Introduction
EST3 System Operation Manual 1.7
Note:
Cabinet configuration option settings determine which
events are routed to the main display and placed in an event
queue.
• The bottom line of the display shows the number of events
in each event queue. The highlight around the event counter
indicates which event queue is displayed in the shaded area.
Note: The event counter stops at 999. It is possible for an
event queue to hold more than 999 events.
Message details
Pressing the Details button displays additional information about
the event displayed on the 3-LCD module's display. Different
detail information is displayed for each of the following:
•Device
• Group
• Guard patrol
• Instruction text
Device details
DETAILS
S000 T000 M000
P:01 C:02 D:0004
STATE ONE
STATE TWO
A001
[3SCRN7.CDR]
Device's logical address
If a device activation causes the event, pressing Details displays
the active device’s logical address in the following format:
P:99 C:99 D:9999
Where:
• P:99 = panel address
• C:99 = rail module address
• D:9999 = device address
Lines below the device address list the off-normal states the
device is currently in.
Group details
If a group activation causes the event, pressing Details displays a
series of panels, one for each device in the group.
