3-LCD operating instructions
EST3 System Operation Manual 2.25
Creating reports
The Reports command generates a report that you can view on
the 3-LCD display module or print on the local printer. Three
types of report are available:
• Device Maintenance
• History
• Revisions
• Modcom Compliance
Device Maintenance: a list of detectors and the amount of
environmental compensation they have used. You can choose to
list devices in several ways.
History: a chronological list of events that have occurred on a
panel since the panel was placed into service or since the last
time the history was cleared.
Two versions of the History report are available: History With
Text, and History Without Text. History With Text is only
available for the panel at which you enter the command. Any
panel can provide History Without Text.
Revisions: a list of all the hardware and software components
installed in a panel and their revision levels.
Modcom Compliance: lists the NFPA 72 compliance level of
all 3-MODCOM modules in a given panel.
To create a Device Maintenance report:
1. Press the Command Menus button , then choose Report.
2. Choose device maintenance.
3. Do one of the following:
• Choose Dirty Devices >80% then enter the target panel
address (PP).
• Choose Dirty Devices >20% then enter the target panel
address (PP).
• Choose Single Device then enter the target device address
(PPCCDDDD).
• Choose Devices On A Card to get the compensation level
for all the detectors on a single loop then enter the target
loop’s logical address (PPCCL).
4. Send the list to the display or to the printer. If you choose to
send the list to the printer, choose Printer 1 if the printer is
connected to port 1 or Printer 2 if connected to port 2.
