Edwards nEXT 730D - Figure 5 Mounting Orientation for Next1230 H; Figure 6 Mounting Orientation for Next1230 H INV

To Next Page

To Previous Page

Figure 5 Mounng orient

aon for nEXT1230H

BC-0035-A

▪ horizontally or verc

ally, with the high-vacuum ange on the boom and in any

orientaon in between (INV versions)

Figure 6 Mounng orientaon for nEXT1230H INV

BC-0034-A

NOTICE: PUMP DAMAGE

The pump can be damag

ed if it is operated in the incorrectly installed orientaon.

Observe the scker on the pump and install the pump only in the permied

orientaon.

Page 13300872820_002_C2

B8J203880_C
