1.3 Safety symbols

The saf

ety symbols on the products show the areas where care and aenon is

necessary.

The safety symbols that follow are used on the product or in the product

documentaon.

Warning/Cauon

An appropria

te safety instrucon must be followed or cauon to a po-

tenal hazard exists.

Warning - Dangerous voltage

Idenes possible haz

ds from dangerous voltages.

Warning - Hot surfaces

Idenes a potenal haz

ard from a hot surface.

Warning - Prot

ecve earth (ground)

Earth point for electrical equipment.

Warning - Use prot

ecve equipment

Use appropriate protecve equipment for the task.

Warning - Risk of explosion

There is a risk of e

xplosion when you do the task.

Page 6300872820_002_C2

B8J203880_C

300872820_002_C2 - Safety and compliance
