19
Current Offset
0.0-10000uA(Total current + current Offset ≤10mA)
Arc Detection
The range is from 1-9(9 is the most Sensitive)
MODEL
SE 7430
SE 7440
SE 7441
SE 7451
SE 7452
INSULATION RESISTANCE
Output Rating
6KVDC/50000MΩ
Output Voltage, Vdc
10-6000
1
±(1% of Setting + 0.5% of Range)
HI and LO-Limit,
resistance, MΩ
0.10-99.99
(HI-Limit：0 = OFF)
0.01
±(0.1% Setting)
100.0-999.9
0.1
1000 – 50000
1
Resistance
Measurement
0.05-999MΩ (under 10-29V)
0.001/0.01/0.1 MΩ
±(15% of Reading + 2 counts)
0.05-999MΩ (under 30-499V)
0.001/0.01/0.1 MΩ
±(7% of Reading + 2 counts)
0.100-999.9MΩ (under 500-6000V)
0.001/0.01/0.1 MΩ
±(2% of Reading + 2 counts)
1000-9999MΩ (under 500-6000V)
1 MΩ
±(5% of Reading + 2 counts)
10000-50000MΩ (under 500-6000V)
1 MΩ
±(15% of Reading + 2 counts)
Ramp Up Timer,
Second
0.1-999.9
0.1
±(0.1% Setting+ 0.05s)
Ramp Down Timer,
Second
0.0, 1.0-999.9
Dwell Time, Second
0, 0.5-999.9(0 = continuous)
Delay Timer, Second
0.5-999.9
Charge LO, current,
uA
0.000-3.500, auto/manual Set
GROUND BOND (SE 7440, SE 7441 & SE 7452 ONLY)
Output Rating
32A/600mΩ/8V
Output AC Current, A
1.00-32.00
0.01
±(2 % of Setting + 0.5% of Range)
Output AC Current, A
(OPT.799)
1.00-40.00
0.01
±(2 % of Setting + 0.5% of Range)
Output Voltage, Vac
Open Circuit Mode
3.00-8.00
0.01
±(2 % of Setting + 3 counts)O.C.
Output Frequency, Hz
50Hz/60Hz ± 0.1%, User Selectable
Output Regulation
±(1% of output + 0.02A), Within maximum load limits, and over input voltage range.
Maximum Loading
1.00-10.00A / 0-600mΩ , 10.01-32.00A / 0-200mΩ
Lead Resistance
Offset, mΩ
0-200
1
±(2% of Setting + 2 counts)at current > 3A
HI and LO-Limit
Resistance, mΩ
0-200 (10.01-32.00A)
1
±(2% of Setting + 2 counts)
0-600 (6.00-10.00A)
0-600 (1.00-5.99A)
±(3% of Setting + 3 counts)at current > 3A
Dwell Timer, Second
0, 0.5-999.9(0 = continuous)
0.1
±(0.1% of Setting + 0.05s)
CONTINUITY (Option)
Output Rating
1A for 1.000 Ohm , 0.1A for 10.00 Ohm ,
0.01A for 100.0 Ohm , 0.001A for 1000 Ohm , 0.0001A for 10000 Ohm
HI and LO-Limit, Ω
0.000-1.000
0.001
±(1% of Setting + 3 counts)
1.01-10.00
0.01
10.1-100.0
0.1
101-1000
1
1001-10000
1
±(1% of Setting + 10 counts)
Dwell Timer, Second
0.0, 0.4-999.9(0 = continuous)
0.1
±(0.1% of Setting + 0.05s)
Resistance Offset, Ω
0.000-10.00
0.001/0.01
±(1% of reading + 3 counts)
