The FWD Angle (degrees) and REV Angle (degrees) in different operation
mode are not the same, details are listed below.
Fwd
Rev
REC
ATC
FWD
Angle
N/A
30
40
50
60
70
80
90
100
120
150
160
180
200
230
250
260
280
300
320
340
360
370
The same with the front
table
REV
Angle
N/A
The same with the front table
The same with the front
table
NOTE
The sum of FWD Angle and REV Angle must be greater than 120°, the motor
system has closed the angle not needed. For example: if you set FWD Angle 30°,
the REV Angle must be setting greater than 90°.
