Attention! In order to avoid injuries, the cable needs to be pulled back into the cable clamp for hiding any type of
cable bits sticking out of it.
The distance between cab-
le clamp and cable housing
should still not exceed 3
mm.
Tighten the two screws of
the cable clamp simul-
taneously with a torque
wrench with 5 Nm.
5mm
Hold the Aluminum cable
housing with your hand.
With the other hand, pull
the cable in order to open
the dropper mechanism.
IWiththispretension,rst
hang the Aluminum cable
housing with the end cap
on the remote lever.
In the last step, the cable
clamp can be hanged on
the remote lever.
