32
Chapter 6 Reference
3.
Attach the arm or stand to the monitor.
Secure the monitor to the arm or stand using the screws specied in the User’s Manual of the arm or
stand.
Note
• When setting the monitor in the portrait orientation, remove the feet on the bottom of the monitor according to
the following procedure.
• Store the removed parts in a safe place.
1. Remove the foot covers.
2. Remove the screw that secures each foot to the monitor.
3. Slide each foot toward the edge of the monitor and remove them as shown
below.
To cover the hole, adhere the seal supplied with this product.
To Next Page
