34
Chapter 6 Reference
6-3. Specications
LCD Panel Type IPS
Backlight LED
Size 58.4 cm (23.0 inch)
Resolution 1920 dots × 1080 lines
Display Size 509.2 mm × 286.4 mm (H x V)
Pixel Pitch 0.265 mm
Display Colors 8-bit color: 16.77 million colors
Viewing Angles 178° / 178° (H / V, typical)
Response Time Gray-to-gray: Approx. 6 ms
(Overdrive setting: Enhanced, typical)
Touch Panel Surface treatment Anti-glare
Surface hardness 5 H
Communication USB-based
Detection method Projected capacitive technology
OS Microsoft Windows 10 (32 bit / 64 bit)
Microsoft Windows 8.1 (32 bit / 64 bit)
Microsoft Windows 7 (32 bit / 64 bit)
Number of
simultaneous touch
points
Max. 10 points
Video Signals Input Terminals Digital DisplayPort × 1, DVI-D × 1 (compatible with HDCP)
Analog D-Sub mini 15-pin
Digital Scanning
Frequency
Horizontal DisplayPort
31 kHz to 68 kHz
DVI
31 kHz to 64 kHz
Vertical 59 Hz to 61 Hz (720 × 400 : 69 Hz to 71 Hz)
Analog Scanning
Frequency
Horizontal 31 kHz to 81 kHz
Vertical 55 Hz to 76 Hz
Frame Synchronization
mode
59 Hz to 61 Hz
Dot Clock
(Max.)
Digital 148.5 MHz
Analog 148.5 MHz
USB Port Upstream port x 1
Downstream port x 2
Standard USB Specication Revision 2.0
Communication Speed 480 Mbps (high) / 12 Mbps (full) / 1.5 Mbps (low)
Supply current Downstream port : Max. 500 mA / 1 port
Audio Input Terminal Stereo mini jack × 1
DisplayPort × 1 (shared with video signal)
- Format: 2ch linear PCM
(32 kHz / 44.1 kHz / 48 kHz / 88.2 kHz / 96 kHz)
Output Terminal Stereo mini jack × 1 (for headphone)
Speaker
1.0 W + 1.0 W
Headphones
2.0 mW + 2.0 mW
Power supply Input 100 - 240 VAC ±10%, 50 Hz / 60 Hz, 0.65 A - 0.35 A
Power Consumption Max. 42 W or less
Power Save
Mode
0.7 W or
less
D-Sub input only connected, USB non-
connection, audio cable non-connection,
"Monitor Settings" - "Input Signal": "Auto"
Standby Mode 0.7 W or
less
D-Sub input only connected, USB non-
connection, audio cable non-connection
To Next Page
