50
M2 - MVB EMD Connector_2
Connector is a standard 9 pin sub D-type, female.
Table A.3: Pin order, connector M2
X3 - VME Connector
Table A.4: Pin order, VME (backplane) connector
6 A.Term_P Positive pole of Terminator Line_A
7 A.Term_N Negative pole of Terminator Line_A
8 B.Term_P Positive pole of Terminator Line_B
9 B.Term_N Negative pole of Terminator Line_B
Pin Signal Description
1 A.Data_P Positive wire Line_A
2 A.Data_N Negative wire Line_A
3 Not Connected
4 B.Data_P Positive wire Line_B
5 B.Data_N Negative wire Line_B
6 A.Term_P Positive pole of Terminator Line_A
7 A.Term_N Negative pole of Terminator Line_A
8 B.Term_P Positive pole of Terminator Line_B
9 B.Term_N Negative pole of Terminator Line_B
Number Signal Number Signal
a32 VCC b32 VCC
a31 not connected b31 not connected
a30 A(1) b30 IRQ(1)~
a29 A(2) b29 IRQ(2)~
a28 A(3) b28 IRQ(3)~
a27 A(4) b27 IRQ(4)~
a26 A(5) b26 IRQ(5)~
a25 A(6) b25 IRQ(6)~
a24 A(7) b24 IRQ(7)~
a23 AM(4) b23 GND
a22 IACKOUT~ b22 not connected
