51
a21 IACKIN~ b21 not connected
a20 IACK~ b20 GND
a19 GND b19 AM (3)
a18 AS~ b18 AM (2)
a17 GND b17 AM (1)
a16 DTACK~ b16 AM (0)
a15 GND b15 not connected
a14 W~ b14 not connected
a13 DS (0)~ b13 not connected
a12 DS (1)~ b12 not connected
a11 GND b11 BG3OUT
a10 not connected b10 BG3IN
a9 GND b9 BG2OUT
a8 D(7) b8 BG2IN
a7 D(6) b7 BG1OUT
a6 D(5) b6 BG1IN
a5 D(4) b5 BG0OUT
a4 D(3) b4 BG0IN
a3 D(2) b3 ACFAIL~
a2 D(1) b2 not connected
a1 D(0) b1 not connected
c32 VCC c16 A(22)
c31 not connected c15 A(23)
c30 A(8) c14 AM(5)
c29 A(9) c13 LWORD~
c28 A(10) c12 SYSRESET~
c27 A(11) c11 BERR~
c26 A(12) c10 SYSFAIL~
c25 A(13) c9 GND
c24 A(14) c8 D(15)
c23 A(15) c7 D(14)
c22 A(16) c6 D(13)
Number Signal Number Signal
