53
Non-metallic parts
The following table specifies the non-metallic parts used in the MVB module.
The values displayed in this table are aimed at helping to estimate the
environmental impact potentially caused by the MVB module in case of fire.
Table A.6: Non-metallic parts
Electrical specifications
The following table specifies the electrical details of the MVB module.
Table A.7: Electrical specifications
Functional specifications
The following table specifies the functional details for the MVB module.
Table A.8: Functional specifications
Material Amount
Polyester 33.5 g
Acrylics 3.8 g
FR 4 58.5 g
Parameter Conditions Value
Supply voltage Low 4.75 V
Nominal 5.00 V
Maximum 5.25 V
Supply ripple/noise All < 20 MHz 50 mV peak-to-peak
Parameter Specification
Reliability (MBTF)
greater than
1200 000 h
estimated from field data at 40 °C ambient temperature
