OPERATION
12 NP-eVENT-16_10-2018
• Remove the front and back cover unscrewing the six screws on the
cabinet side.
• Unscrew the four screws and remove the internal back cover (18).
• Remove all packing elements above (21) and under the compressor (20).
• Screw the internal back cover back on, connect the ground wire, screw
the front and back cover and insert the suction filter.
Please retain the packing elements for future compressor transportation.
Compressed air connection
The medical compressor is equipped with quick couplings WALL (9) and
OUT (10) to the rear of the cabinet.
Connect the pressure hose from the given equipment/respiration equipment
to the quick coupling OUT (10) -outlet compressed air.
Connect the compressed air line from the central distribution line o the quick
coupling WALL (9) -inlet compressed air. Air from the distribution system is
automatically connected through the compressor to the OUT outlet port. In
this configuration, the compressor serves as a backup source of compressed
air. If the air pressure from the central distribution system is reduced, the
compressor automatically switches on and there is no interruption in the
supply of continuously pressurized air at the outlet of the compressor.
Please note that the air supply from the central distribution line
entering the compressor must be medical grade air (particulate size,
humidity.) The compressor does not modify the air from the central
distribution line.
The hose connecting the compressor to the respiration equipment
must not pass through a cold environment i.e. placed on the ground. It
should be as short as possible with no kinks (this may cause water to
condense inside the hose).
Electrical connection
The compressor comes with a plug containing an appropriate
protective contact (ground.) Adhere to local electrical regulations. The
voltage and frequency of the mains must comply with the
specifications on the data label.
The electrical cord must not be stressed or have any tension exerted
upon it, and must always be free.
• The socket must be accessible for safety reasons so that the equipment
can be safely disconnected in case of an emergency.
• The relevant current circuit must be protected.
