MAINTENANCE
18 NP-eVENT-16_10-2018
Safety valve check
The safety valve is adjusted to 8 bar (116 psig) by the manufacturer,
then tested and marked. It must not be readjusted.
• Turn the screw of the safety valve
(17) several rotations to left until the
safety valve puffs.
• Only allow the safety valve freely
puff for a short period of time.
• Turn the screw to the right until it is
tight, closing the valve.
Never use the safety valve to release pressure in the air tank. This could
damage the safety valve.
Replacing the suction filter
• Unlock the cover and pull it out.
• Replace the filter
• Lock the cover
Spare part:
Suction filter 05W POLYESTER, Item 025200194-000
Replacing the blow down filter
• Loosen lock on filter (14) by pulling it down.
• Slightly turn the cover of the filter and pull it out.
• Unscrew the filter holder.
• Replace filter (C), screw in the filter holder.
• Place the cover of filter and secure it by turning to right till it locks.
