OPERATION
NP-eVENT-16_10-2018 13
• Connection of the ground connection (7) to other equipment must adhere
to local electrical regulations.
• Fasten the electrical cord through the holder (8).
First operation
• Make sure the stabilizing screws used during transport were removed.
• Check that the connection to the compressed air supply is correct.
• Check for proper connection to the main power supply.
• Switch on the pressure switch (6) to position “I”.
After the compressor is first put into operation, the air tank of the compressor
is pressurized to a ‘switching-off’ pressure and the compressor will then be
automatically switched off. During the following time period the compressor
works in an automatic mode, i.e. according to the consumption of
compressed air; the pressure switch controls compressor operation.
During operation, the equipment releases condensed water from the
condenser (filter) automatically to the evaporation tray.
Accessories
Holder for supporting equipment - Item 604011346-000
The holder (19) is suitable for supporting a respiratory apparatus with
accessories. Please remove the plug in the middle of the upper side before
installation. Screw the holder into the socket and tighten it fast.
Technical data:
Diameter 25 mm
Height 1100 mm above the floor
The maximum holder load is 28 kg. The centre of gravity of supporting
equipment must be in the axis of the holder, max. 1100 mm above the floor.
Consult the manufacturer regarding any other connections.
The manufacturer is not liable for any damage resulting from excessive
loads on the equipment!
The supplier is obliged to ensure the acceptability of a load delivered
by a supplied accessory.
It is forbidden to lean or press against an installed accessory for
support!
The equipment must be lifted when travelling over an obstacle!
Supporting equipment must be disassemble before transport!
