Opening an existing batch (ST)
By selecting Batch/Open Existing Batch on the Model T, the user will
find a list of all the batches that have already been created, together
with the number of readings stored in each batch.
To open a particular batch use the up and down arrow soft keys and
select the appropriate batch.
The Elcometer 456 will return the gauge to the main reading screen
and the selected batch name will be shown at the top of the display
(together with a unique gauge batch id number - allowing no two
batches to have exactly the same name).
As the Model S only has one batch, the batch will open automatically.
Copying an existing batch (T)
By selecting Batch/Copy Batch the user will find a list of all the
batches that have already been created, together with the number of
readings stored in each batch.
To copy a particular batch use the up and down arrow soft keys and
select the appropriate batch.
The Elcometer 456 will then copy all the batch settings - calibration
and foil values, batch type, cal method, warning limits, and the batch
name - and then ask the user whether they wish to rename the batch.
Pressing the Yes softkey the user will then be asked to rename the
batch using the renaming procedure described on page 27.
Pressing the No softkey (or pressing the Esc softkey whilst in the
renaming procedure) will make the Elcometer 456 copy the existing
batch name to the new batch - thereby two batches will have the same
batch name.
Copying a batch does not copy the individual readings within that
batch.
Clearing an existing batch (ST)
By Selecting Batch/Edit Batch/Clear Batch on the Model T, the user
will find a list of all the batches that have already been created,
together with the number of readings stored in each batch.
To clear a particular batch’s individual readings only, use the up and
down arrow soft keys and select the appropriate batch.
www.elcometer.com
29
