As the Model S only has one batch, it is selected automatically.
After a request for confirmation, the gauge will clear the readings from
the selected batch and return the gauge to the list of batches (T) or the
Batch Menu (S).
To clear another batch (T), repeat the procedure. To return the gauge
back to the previous menu, press the Back softkey.
The user can clear all batches via Batch/Edit Batch/Clear Batch/All
Batches (T).
Reviewing an existing batch (ST)
By selecting Batch/Review Batch the user will find a list of all the
batches that have already been created, together with the number of
readings stored in each batch.
To review a particular batch use the up and down arrow soft keys and
select the appropriate batch. As the Model S only has one batch, it is
selected automatically.
The Elcometer 456 will then open up the Review Batch menu, allowing the
user to:
Ÿ Review the statistics of the batch
Ÿ Review the batch information, including:
Ÿ the date and time the batch was created
Ÿ the batch type - normal, counted average or IMO PSPC
Ÿ the probe type and serial number used to take the readings
Ÿ the calibration method - smooth, rough/2 point, etc.
Ÿ the batch limits (if set)
Ÿ Review the batch’s calibration information, including:
Ÿ the date and time the batch was last calibrated or verified
Ÿ the substrate type (or types if using an FNF probe)
Ÿ the probe type and serial number
Ÿ the calibration method - smooth, rough/2 point etc.
Ÿ the foil values used in the calibration
Ÿ Review the individual readings. The Elcometer 456 displays:
Ÿ the readings in numerical order, the first reading is at the top
Ÿ the substrate, time and date of measurement
Ÿ icons indicating a reading above “ ” or below “ ” the limit
Ÿ deleted readings icon “ ” is displayed if “Delete With Tag”
selected, (see page 26 for more information).
Ÿ Review a graph of the individual readings (T), see page 31.
www.elcometer.com 30
