ElectrIQ PowerPod 2 - AC-Coupled Model Dimensions and Weight; AC-Coupled Dimensions, Weight, and Warranty

86 Installation Manual
Product Model
PP2-
AC-10/15/20-9600
PP2-
AC-10/15/20-8600
PP2-
AC-10/15/20-7600
PP2-
AC-10/15/20-7000
PP2-
AC-10/15/20-6000
PP2-
AC-10/15/20-5000
Dimensions (W / H / D)
(inverter)
16.3in x 31.1in x 6.9in (415mm x 791mmx 175mm)
Dimensions (W / H / D)
(auto-transformer)
13.6in x 10.9in x 6.9in (345mm x 280mmx 175mm)
Weight (inverter) 70.5lb (32kg)
Weight (auto-transformer) 50lb (22kg)
Warranty Inverter 10 years
STANDARD COMPLIANCE
Safety
UL9540, UL1973, UL1741SA, CSA 22.2
Grid Connection Standards IEEE 1547A, IEEE 1547.1
Emissions FCC part15 class B
Standards Rule 21, HECO
Standards in progress Hawaii TrOV2, FVRT
Battery Model
Battery Zhongneng Technology Lithium-ion
Battery type Lithium-ion
Cells CATL
Chemistry LFP - Lithium iron phosphate
Number of 2.5 kWh
Modules
4/6/8 in Series
Nameplate Capacity 10/15/20 kWh
Battery Layout 1 parallel 32/48/64 series
Voltage, Nominal 102.4 VDC (89.6 – 115.2 VDC)/ 153.6 VDC (134.4 – 172.8 VDC/ 204.8 VDC (179.2 – 230.4 VDC)
Continuous Charge Current 50 ADC
Continuous Discharge
Current
50 ADC
Maximum Charge Current 60 ADC
Maximum Discharge Current 60 ADC
Continuous Charge Power
(Nominal)
5120/7700/9600 W 5120/7700/8600 W 5120/7600/7600 W 5120/7000/7000 W 5120/6000/6000 W 5000/5000/5000 W
Continuous Discharge
Power (Nominal)
5120/7700/9600 W 5120/7700/8600 W 5120/7600/7600 W 5120/7000/7000 W 5120/6000/6000 W 5000/5000/5000 W
Maximum Charge Power
(Nominal)
6150/7700/10,240
W
6150/7700/10,240
W
6150/7700/9120 W 6150/7700/8400 W 6150/7200/7200 W 6000/6000/6000 W
Maximum Discharge
Power (Nominal)
6150/7700/10,240
W
6150/7700/10,240
W
6150/7700/9120 W 6150/7700/8400 W 6150/7200/7200 W 6000/6000/6000 W
Charge Temperature (0 °C to 55 °C)
Discharge Temperature (-20 °C to 55 °C)
Communication Interface RJ-45 RS-485
Power Switch, ON / OFF Yes
Cycles For Daily Cycle Applications
Service Life (40% Capacity
Reduction)
10 Years
Altitude 2000 m
Dimensions (W / H / D)
(BMS & battery module)
17.5” x 7.5” x 8.9” / 445mm x 190mm x 226mm
Dimensions (W / H / D) 10
kWh assembled battery
enclosure
27.5” x 50” x 9” / 700mm x 1270mm x 230mm
Appendix / Technical Specifications (AC)
