4.3. TECHNICAL SPECIFICATIONS (DC- COUPLED)
Product Model
PP2-DC-
10/15/20-9600
PP2-DC-
10/15/20-8600
PP2-DC-
10/15/20-7600
PP2-DC-
10/15/20-7000
PP2-DC-
10/15/20-6000
PP2-DC-
10/15/20-5000
Configuration 4/6/8 Batteries in Series
Utility Compatibility Per UL 1741SA
AC OUTPUT / GRID
Rated AC Power Output
(To Grid, From Solar)
@ 25°C
9600/9600/9600 VA 8600/8600/8600 VA 7600/7600/7600 VA 7000/7000/7000 VA 6000/6000/6000 VA 5000/5000/5000 VA
Rated AC Power Output
(To Grid, From Solar)
@ 45°C
9600/9600/9600 VA 8600/8600/8600 VA 7600/7600/7600 VA 7000/7000/7000 VA 6000/6000/6000 VA 5000/5000/5000 VA
Rated AC Power Output
(To Grid, From Battery)
75% DOD @ 25°C
5000/7500/9600 VA 5000/7500/8600 VA 5000/7500/7600 VA 5000/7000/7000 VA 5000/6000/6000 VA 5000/5000/5000 VA
Rated AC Power Output
(To Grid, From Battery)
75% DOD @ 45°C
5000/7500/9600 VA 5000/7500/8600 VA 5000/7500/7600 VA 5000/7000/7000 VA 5000/6000/6000 VA 5000/5000/5000 VA
AC Grid Voltage L-L: 211 to 264V, 1Ø
AC Frequency 60Hz 59.3 to 60.5Hz ± 0.05Hz
Maximum Continuous
Output Current
0 to 40 A
(@240 V)
0 to 35.8 A
(@240 V)
0 to 31.7 A
(@240 V)
0 to 29.2 A
(@240 V)
0 to 25 A
(@240 V)
0 to 20.8 A
(@240 V)
AC Circuit Breaker (grid) No
Ground-Fault Isolation
Detection
Integrated Detection Included
Charge Battery from AC Yes
THD (current) < 5 %
Operating (Standy) Power
Consumption
<40 W
Operation Temperature
Range
-20 to 55°C (power derated above 40°C)
Operation Humidity 10% to 90% Non-condensing
Thermal Management Forced convection
Noise Level, Maximum < 45 dBA
Output (AC) / BACKUP
LOAD
Rated AC Backup Power
Output @25°C From Solar
9600 VA 8600 VA 7600 VA 7000 VA 6000 VA 5000 VA
Maximum Overload 60 s
@25°C & 240 V From Solar
11,520 VA 10,320 VA 9120 VA 8400 VA 7200 VA 6000 VA
Rated Output Current
From Solar (120 V
unbalanced/240 V balance)
40/40 A (@120
and 240 V)
40/35.8 A
(@120 and
240 V)
40/31.7 A
(@120 and
240 V)
40/29.2 A
(@120 and
240 V)
40/25 A (@120
and 240 V)
40/20.8 A
(@120 and
240 V)
AC Backup Power Output
From Battery (DOD 95%)
4500/6750/9000 VA 4500/6750/8600 VA 4500/6750/7600 VA
4500 VA 4500 VA 4500 VA
Maximum Overload 60
s @25°C From Battery
(DOD 95%)
5400/8100/10,
800 VA
5400/8100/10,
320 VA
5400/8100/9120 VA
5400 VA 5400 VA 5400 VA
AC Backup Power Output
From Battery (SOC 60 to
100%)
5350/7900/9600 VA 5350/7900/8600 VA 5350/7600/7600 VA
5350 VA 5350 VA 5000 VA
Maximum Overload 60 s
@25°C From Battery (SOC
60 to 100%)
6400/9500/11,
520 VA
6400/9500/11,
320 VA
6400/9120/9120 VA
6400 VA 6400 VA 6000 VA
AC Backup Output Voltage 120/240 VAC
AC Frequency 60Hz
