89Installation Manual
Appendix / Technical Specifications (DC)
Product Model
PP2-DC-
10/15/20-9600
PP2-DC-
10/15/20-8600
PP2-DC-
10/15/20-7600
PP2-DC-
10/15/20-7000
PP2-DC-
10/15/20-6000
PP2-DC-
10/15/20-5000
Ground-Fault Isolation
Detection
Integrated Detection Included
AC Circuit Breaker
(inverter)
No
AC Circuit Breaker (inverter
bypass, grid connect)
No
THD (voltage) < 3 %
Power Factor > 99%
Automatic Switchover
Time
< 1sec
DC INPUT / PV / String
Inputs
4 4 4 2 2
Maximum Power (EA
MPPT/Total)
6000/15,000 W 6000/12,900 W 6000/11,400 W 6000/10,500 W 6000/9000 W 6000/7500 W
Operation Voltage Range 80-550 VDC
MPPT Voltage Range 300 to 500 VDC
Minimum Start Voltage 95 VDC
Maximum Input Current 12.5 / 12.5 / 12.5 / 12.5 A 12.5 / 12.5 A
Maximum PV Panel I(sc)
Allowed
15.2 / 15.2 / 15.2 / 15.2 A 15.2 / 15.2 A
PV Switch Yes, 8P
Reverse-Polarity Protection Yes
Ground-Fault Isolation
Detection
Integrated detection included
DC INPUT / BATTERY
Rated Charge / Discharge 50 A / 50 A
Maximum Charge /
Discharge
50 A / 50 A
DC Voltage Range 80-495
Battery Capacity (Range) 10 to 20 kWh
Battery Types Supported Lithium-ion (LFP)
DC Circuit Breaker Yes
DC Fuse on Plus Terminal Internal Fuse, not field replaceable
EFFICIENCY
PV Max. Eciency 97.6%
PV CEC Eciency 97.2%
Battery Charged By PV
Max. Eciency
98.1%
Battery Charge/discharge
to AC Max. Eciency
96.6%
CEC Eciency 96.1%
OPERATIONAL FEATURES
AND MODES
Islanding Neutral Forming Transformer
Back-up (default) Ye s
Self Consumption Yes
Prioritized Charging from
Renewables
Yes
Grid Support - Zero Export Yes
Time-Of-Use Grid Export Yes
Genset Integration No
