Appendix / Technical Specifications (DC)
Product Model
PP2-DC-
10/15/20-9600
PP2-DC-
10/15/20-8600
PP2-DC-
10/15/20-7600
PP2-DC-
10/15/20-7000
PP2-DC-
10/15/20-6000
PP2-DC-
10/15/20-5000
Grid Support/Demand
Response
Yes
Home current monitoring
(L1 & L2 CTs)
Yes
Over Current Protection Yes
Short Protection Yes
Over Voltage Protection Ye s
Battery Reverse Polarity
Protection
Yes
ADDITIONAL AND
OPTIONAL FEATURES
Supported Communication
Interfaces
WiFi & Cellular
System Monitoring and
Network Communications
Cloud-Based Dashboard
Interface Protocol Proprietary
Loads Disconnect Isolation Yes
Inverter Bypass Switch Automatic
Rapid Shutdown
functionality for NEC 2014
690.12
External option
Arc Fault Protection (Type
1) for NEC 2011 690.11
compliance
Yes
Insulation Resistance
Detection
Yes
Revenue Grade Data,
ANSI C12.
Optional
NEMA 3R Enclosure Standard
Dimensions (W / H / D)
(inverter)
16.3in x 31.1in x 6.9in (415mm x 791mmx 175mm)
Dimensions (W / H / D)
(auto-transformer)
13.6in x 10.9in x 6.9in (345mm x 280mmx 175mm)
Weight (inverter) 70.5lb (32kg)
Weight (auto-transformer) 50lb (22kg)
Warranty Inverter 10 years
STANDARD COMPLIANCE
Safety
UL9540, UL1973, UL1741SA, CSA 22.2
Grid Connection Standards IEEE 1547A, IEEE 1547.1
Emissions FCC part15 class B
Standards Rule 21, HECO
Standards in progress Hawaii TrOV2, FVRT
Battery Model PP2-10/15/20 KWH
Battery Zhongneng Technology Lithium-ion
Battery type Lithium-ion
Cells CATL
Chemistry LFP - Lithium iron phosphate
Number of 2.5 kWh
Modules
4/6/8 in Series
Nameplate Capacity 10/15/20 kWh
Battery Layout 1 parallel 32/48/64 series
