ElectrIQ PowerPod 2 - DC-Coupled Model Dimensions and Weight; DC-Coupled Dimensions, Weight, and Warranty

91Installation Manual
Appendix / Technical Specifications (DC)
Product Model
PP2-DC-
10/15/20-9600
PP2-DC-
10/15/20-8600
PP2-DC-
10/15/20-7600
PP2-DC-
10/15/20-7000
PP2-DC-
10/15/20-6000
PP2-DC-
10/15/20-5000
Voltage, Nominal 102.4 VDC (89.6 – 115.2 VDC)/ 153.6 VDC (134.4 – 172.8 VDC/ 204.8 VDC (179.2 – 230.4 VDC)
Continuous Charge Current 50 ADC
Continuous Discharge
Current
50 ADC
Maximum Charge Current 60 ADC
Maximum Discharge
Current
60 ADC
Continuous Charge Power
(Nominal)
5120/7700/9600 W 5120/7700/8600 W 5120/7600/7600 W 5120/7000/7000 W 5120/6000/6000 W 5000/5000/5000 W
Continuous Discharge
Power (Nominal)
5120/7700/9600 W 5120/7700/8600 W 5120/7600/7600 W 5120/7000/7000 W 5120/6000/6000 W 5000/5000/5000 W
Maximum Charge Power
(Nominal)
6150/7700/10,240
W
6150/7700/10,240
W
6150/7700/9120 W 6150/7700/8400 W 6150/7200/7200 W 6000/6000/6000 W
Maximum Discharge
Power (Nominal)
6150/7700/10,240
W
6150/7700/10,240
W
6150/7700/9120 W 6150/7700/8400 W 6150/7200/7200 W 6000/6000/6000 W
Charge Temperature (0 °C to 55 °C)
Discharge Temperature (-20 °C to 55 °C)
Communication Interface RJ-45 RS-485
Power Switch, ON / OFF Yes
Cycles For Daily Cycle Applications
Service Life (40% Capacity
Reduction)
10 Years
Altitude 2000 m
Dimensions (W / H / D)
(BMS & battery module)
17.5” x 7.5” x 8.9” / 445mm x 190mm x 226mm
Dimensions (W / H / D) 10
kWh assembled battery
enclosure
27.5” x 50” x 9” / 700mm x 1270mm x 230mm
Dimensions (W / H / D) 5
kWh assembled battery
enclosure
27.5” x 50” x 9” / 700mm x 1270mm x 230mm
Weight BMS 33 lb. / 15 kg
Weight (battery only, 1
module)
62 lb. / 28 kg
Weight (Total batteries) 400 lb. (180 kg) / 535 lb. (240 kg) / 705 lb. (320 kg)
Warranty Battery 10 years
